Caterpillar 3406 Seawater Pump 5N4852, 3N4851, 3N4852, Jabsco 17970-0000 Replacement JPR-CT3406
Caterpillar 3406 Seawater Pump 5N4852, 3N4851, 3N4852, Jabsco 17970-0000 Replacement JPR-CT3406
Regular price
$3,520.00 AUD
Regular price
Sale price
$3,520.00 AUD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Replacement sea water cooling Pump for CAT 3406 marine engines.
Engine Model: 3406
Caterpillar 3406, PUMP P/N: 5N4852, 3N4851, 3N4852
Replacement sea water pump Jabsco 17970-0000
This is a JMP Marine pump JPR-CT3406.
Pump Parts:
| JMP | CAT | DESCRIPTION | QTY | REMARK |
|---|---|---|---|---|
| JPR-CT3406 | 3N4851 | SEA WATER PUMP | 1 | |
| BER0005 | 1B3687 | BALL BEARING | 2 | |
| BOL0005 | 3F7856 | SCREW, END COVER | 6 | |
| CAMSET0018 | 3N4860 | CAM LINER | 1 | ALUMINUM BRONZE |
| COV0011 | 3N4854 | END COVER | 1 | |
| GAK0008 | 3N4861 | GASKET, END COVER | 1 | |
| 8300-01 | 3N4859 | IMPELLER | 1 | |
| MCSSET0007 | 3N5632 | MECHANICAL SEAL SET | 1 | |
| PIN0002 | 3N4855 | DOWEL PIN | 2 | |
| RET001301 | 3N4863 | OIL SEAL | 1 | |
| SHA0046 | 3N4858 | SHAFT | 1 | |
| SLI0003 | 1L4786 | SLINGER | 1 | |
| SNP0008 | 3N7759 | SNAP RING (SMALL) | 1 | |
| SNP0013 | 1L4775 | SNAP RING (LARGE) | 1 | |
| WER0010 | 3N4862 | WEAR PLATE | 2 | |
| JSM 0005 | N/A | MINOR KIT | 1 | |
| JSK002601 | N/A | MAJOR KIT | 1 | ALL INTERNAL PARTS |
