Onan MDKDS Sherwood G-1012 (G1009) Seawater Pump Replacement JRP-G1012
Onan MDKDS Sherwood G-1012 (G1009) Seawater Pump Replacement JRP-G1012
Regular price
$990.00 AUD
Regular price
Sale price
$990.00 AUD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Seawater pump replaces Sherwood G1012, G-1012
G1009 G-1009 was replaced by G1012. The hose connections are not the same and will require replumbing when replacing the G1009 with the G1012.
Replaces Onan seawater pump 132-0464 (Spec A-B) / Cummins A032Y747 (Spec C).
Used on Onan MDKDS / MDKBT / MDKBU
Pump Mounting O-ring not included click hear to add LP 509-0450
Replacement Impeller - JMP 7300-01
This is a non-OEM, aftermarket part by JMP Marine JPR-ON7312 (SG1012).
| Pos |
Description |
Sherwood Number |
Replacement Part |
Included Minor Kit |
Included Major Kit |
|---|---|---|---|---|---|
| Minor Kit | JSM0161 | ✔ | |||
| Major Kit | ✔ | ||||
| Impeller | 10615K | ||||
| Woodruff Key | 4432 | Original Part | |||
| Lip Seal | 10514C | Original Part | |||
| Mechanical Seal Assembly | 22117 |
AN 6212 |
|||
| Circlip Retaining Ring | 4258 x 2 | AN 2394 | |||
| Bearing | 12211 x 2 | ||||
| Wear Plate | 19295 | ||||
| Cam | 10929 | AN 6243 | |||
| Cover Plate | 25069 | ||||
| Mounting O-ring | Onan 509-0450 |
